Ref.: AGM

Drying processes with hot air generators fully configurable in flow and air pressure


AGM hot air generators are units that work completely autonomously, they do not need heat dissipative elements, which reduces acquisition and installation costs.
They can run on diesel, natural gas or propane gas and their function is based on heating the air drawn in by the fans and driving the hot air inside the room to be heated or dried.
Its design allows the application of all types of low, medium or high pressure fans according to the needs of each installation.
The main advantages over other heating systems are:
- Reduction of acquisition and installation costs.
- Very fast heating or drying system.
- Air diffusion can be direct or a network of ducts can be applied.
- 90% combustion efficiency.
- Possibility of supply with low, medium or high pressure fans.

Main features:

- High performance combustion oven, made of AISI-430 stainless steel in the areas most exposed to heat.
- Exterior panel made of galvanized steel lacquered in polyester powder and oven dried.
- Thermal insulation of the areas most exposed to heat.
- Electrical control and safety panel according to European regulations.
- Control thermostats (Fan / Burner / Thermal safety).
- Hot air outlet through grilles or ductwork.
- Security system to control the correct depression in the combustion chamber.
- Centrifugal fan with low noise level (optional).
- Room thermostat (optional).

Allowed fuels:

- Diesel oil
- Natural gas
- Propane gas

Available powers:

43 to 145 kW


3.500 to 9.200 m3/h

Heating capacity:

990 to 3.115 m3


Industrial premises, drying processes, greenhouses, farms, etc..


More information on Tel. +34 93 851 15 99

Download PDF Catalog Request information
